Rotary screen suitable for fine materials

Basic Info

Model No.: CWGT-

Brand: CWJX

Type: Circular, Stationary Or Mobile

Function: High Frequency Vibrating Screen

Transmission Structure: Vibrating Screen

Usage: Lightweight Fine Shaker

Works: Rotary Vane Shaker

Object: Chemicals

Shaft Number: Single

Running Track: Circular Vibrating Screen

Supporting Device: Coil Spring

Warranty: 1 Year

Customized: Customized

Condition: New

Application: Ore

Voltage: 220v/380v

Noise: Below 75db

Weight: Variable

Material: SUS304 Or Q235A

After-sales Service: Free Spare Parts, Online Support, Video Technical Support

Screening Efficiency: Over 95% .

Screen Mesh: 3-10mm

Capacity: 700-1500kg/hr

Additional Info

Packaging: plywood case or as required

Productivity: variable

Transportation: Ocean,Land,Air

Place of Origin: Henan, China (Mainland)

Supply Ability: 15 sets of 20 days

Certificate: CE ISO SGS

Port: Qingdao,Shanghai,Shenzhen

Payment Type: L/C,T/T

Incoterm: FOB

Product Description

Product Details

Product description

The main structure of the drum screen (also known as the circular rotary screen) is a screening cylinder, which is made by a bitter dry circular deceleration system to rotate the screening cylinder at a certain rotation speed, and the material is separated from the top to the bottom through the screening cylinder. The fine material is discharged from the lower portion of the front end of the screening cylinder, and the coarse material is discharged from the lower end of the screening cylinder. The drum screen can be provided with a comb-type cleaning mechanism, and the relative movement of the comb-type cleaning mechanism and the screening cylinder can be achieved during the screening process to achieve the effect of uninterrupted cleaning of the sieve body, so that the screening cylinder is in the whole working process. Always keep clean, non-sticky, non-blocking, and does not affect the screening effect.

Product Application

1. Stone yard for grading of large and small stones, and separation of soil and stone powder.

2. Separation from sand and gravel in the sandstone field.

3. Coal industry for the separation of lump coal and pulverized coal and coal washing (part of coal washing machinery)

4. Chemical industry, the mineral processing industry for the classification of large and small blocks and separation of powdery substances.

Rotary Drum Scree

Features

1. Wide adaptability of materials: Rotary sieves are widely used in screening various materials. Whether it is inferior coal, slime, soot or other materials, they are smoothly screened.

2. High screening efficiency: The equipment can be equipped with a comb-type cleaning mechanism. During the screening process, the material entering the screening cylinder can be sieved according to the dirtiness and impurities, thus improving the screening efficiency of the equipment.

3. The sieve component is large and easy to enlarge: in the same size, the circular area is larger than other shapes, so the effective area of the screening is large, so that the material can fully contact the screen, so the sieve component per unit time Big. Because of its simple structure, convenient layout, novel and mature technology, it is easy to enlarge.

4, the working environment is good: the entire screening cylinder can be sealed with a sealed isolation cover, completely eliminating the phenomenon of dust flying, block-like splashing during the screening cycle, and avoiding pollution to the working environment.

Packing & Delivery

Rotary Drum Scree

Our Company

Rotary Drum Scree

Our Service

1. You can check our products on Alibaba.com before you sell. If you have any questions, please feel free to contact us.

2. We provide detailed video teaching installation during sales.

3. We have a one-year warranty after the sale.

Certifications

Rotary Drum Scree

Contact Us
1. Which machine do you need?
Such as Vibrating screen, conveyor, Vibrating Feeder, Pin mill machine, mixer machine and other equipments.

2. Which kind of material you are going to process?
Our equipment could used in mining, metallurgy, power plant, chemical industry, etc.
You can give us the material that you are going to process and we will provide suitable equipment for you as soon as possible.

3. What's the production capacity you want?
Could customized according to kgs or cubic meters per hour.

4. You want only a machine or a complete production line?

Please tell me your E-mail and Phone, I will give you factory price with full specification and you will know all details about machine and discount.
